Iterms | Parameter |
Frequency | TD-LTE B38/B39/B40/B41 FDD-LTE B1/B3/B8 WCDMA B1/B8 TD-SCDMA B34/B39 TWO-band EDGE/GPRS/GSM Compatibility LTE CAT4, 3GPP R9 |
Power | FDD/TDD： Power Class 3( 23±2.7dBm) WCDMA : Power Class 3 (+24dBm +1/-3dBm) GSM/GPRS 850MHz/900MHz: Power Class 5 (+33dBm ±2dBm) GSM/GPRS 1800MHz/1900MHz: Power Class 0 (+30dBm ±2dBm) |
Data | GSM CS:UL 9.6kbps/DL 9.6kbps GPRS:171.2kbps WCDMA:UL 11.5Mbps/DL 42.2Mbps FDD:UL 50Mbps/DL 150Mbps |
Speech coding | HR/FR/EFR/AMR Analog audio CSFB and VoLTE(optional) |
Rx Freq. Range | 925.2~959.8MHz 1805.2~1879.8MHz 2010-2025Mhz 1880-1920Mhz 2555-2655Mhz 2300-2400Mhz |
Power Class | 4 1 3 |
Duplex frequency offset | 45 MHz 95 MHz |
Duplex offset (time RX-TX) | 4 time slot 4 time slot |
Channel spacing | 200 KHz 200 KHz 100Khz |
Modulation type | 0.3 GMSK 0.3 GMSK QPSK |
Frequency error | < ±50Hz (0.1ppm) < ±90Hz (0.1ppm) |
Phase error | Peak: < 13 degrees Peak: < 13 degrees |
| RMS: <3 degrees RMS: <3 degrees |
Receiver BER at -102 dBm | FER <0.12% Class 1b RBER <0.41% Class 2b RBER <2.4% FER <0.12% Class 1b RBER <0.41% Class 2b RBER <2.4% |
TD-SCDMA BER At -108dBm | BER <0.1% |
TDD -LTE BLER At -95.3dBm（10M） | ACK>=95% |
